Polyester Woven Dryer Screen

Brand Name:
REKING
Place of Origin:
Hebei
Quality Inspection:
ISO9001
Port:
Xingang, Tianjin
Minimum Order Quantity:
200 Set/Sets
Supply Ability:
3000 Set/Sets per Month
Payment Terms:
L/C,T/T

Availability:

Quantity:



Inquire Add to Basket

Product Description

1-yijin

polyester pulp washing fabric

Mainly used for horizontal belt type pulp washing machine, vacuum pulp washing machine and drum wash pulp machine.

Polyester Plain Weave F

Plain Woven Polyester Mesh Series

Two-shed and three-shed plain woven mesh are mainly used in making paper pulp, packing paper, fiber paper and other special wire mesh products.

Type	Filament diameter mm		Density/root cm		Tensile strength		weight kg/m2	Thickness mm	Mess mm	Aperture mm	Air permeability m3/m2h	CFM 127Pa	L/m2/S 200Pa	open aven
Type	warp	weft	warp	weft	surface	joint	weight kg/m2	Thickness mm	Mess mm	Aperture mm	Air permeability m3/m2h	CFM 127Pa	L/m2/S 200Pa	open aven
021002bule	1.0	1.0	2.85	2.65	1600	650	0.60	1.85	7.10/6.73	2.50/2.77	32000	2000	12600	52.55
031002bule/white	1.0	1.0	3.2	3.25	1600	650	0.80	1.86	8.10/8.20	2.12/2.07	25600	1600	10500	45.9
03902	0.9	0.90	3.9	3.65	1600	650	0.55	1.70	9.60/9.30	1.66/1.83	20000	1250	9000	46.58
04902	0.9	0.9	4.65	4.7	1600	650	0.95	1.66	12/12	1.25/1.22	17600	1170	8100	33.55
04602	0.5	0.60	4.4	5.2	1600	650	0.58	1.23	12/13.2	1.72/1.32	19000	1187	8500	53.32
05602	0.60	0.60	5.9	5.6	1600	650	0.62	1.1	14.98/14.2	1.09/1.18	18000	1125	8210	42.89
05802	0.80	0.80	5.1	5.3	1600	650	0.89	1.48	13/13.5	1.16/1.08	15840	990	6350	34.09
06652	0.65	0.65	7.4	6.8	1600	650	0.65	1.19	18.8/17.3	0.70/0.82	14400	1190	7500	28.96
06802bule/white	0.80	0.80	6.6	6.5	1600	650	0.85	1.45	16.8/16.5	0.72/0.73	11600	725	4600	22.65
06702bule/white	0.70	0.70	7	7	1600	650	0.77	1.3	17.8/17.8	0.72/0.72	11000	690	4550	26.01
07802	0.80	0.80	7.8	7	1600	650	1.1	1.45	20.3/18	0.32/0.54	5920	370	3620	16.54
09502	0.50	0.50	9.7	10.3	1600	650	0.50	0.90	25/26.2	0.53/0.47	10100	634	4130	24.97
12502	0.50	0.50	13.5	8.5	1600	650	0.63	0.95	34.3/21.6	0.24/0.65	6500	6280	1960	18.68
09452	0.45	0.45	10	8.6	1600	650	0.45	0.88	25.4/21.8	0.55/0.71	15570	970	6150	33.71
08603	0.50	0.60	9.4	9	1600	650	0.60	0.95	23.8/23.1	0.56/0.51	9000	560	2760	24.38
08502	0.50	0.50	9.5	8.6	1600	650	0.89	0.47	24.13/21.8	0.50/0.65	10140	634	4130	29.93
06803	0.70	0.80	7	5.5	1600	650	0.75	1.53	17.8/14	0.72/1.0	16000	1000	6280	28.56
Strong alkali resistance PA061002	1	1	4.5	5.5	1600	650	0.65	1.63	17/14	0.35/0.60	5920	370	3620	14.85
09603	0.5	0.6	10.5	9.2	1600	650	0.65	1.05	26.67/23.4	0.45/0.48	8300	518	2350	44.87
07803	0.8	0.8	8	8	1600	650	1.15	1.66	20.3/20.3	0.45/0.45	6400	400	2550	16.26
07903	0.8	0.9	7.6	6.5	1600	650	1.25	1.76	19.3/16.5	0.51/0.63	9184	574	3720	12.96
